SF6 LaserCheck P3:FH

SF6 Containment Test System

The SF6 LaserCheck P3:FH is an award-winning SF6 containment test system using the ANSI/ASHRAE Standard 110-2016 for testing the performance of laboratory fume hoods.

Inquire Now

Features

The SF6 LaserCheck P3:FH is unlike conventional absorption spectroscopy, the advanced principle of photoacoustic gas detection makes it possible to determine, and compensate for, a beginning contamination of the internal measuring chamber. This ability accounts for its excellent long-term stability of measurement. Ideal for laboratory settings containing fume hoods, this product can be found in university chemical labs as well as industrial labs. The SF6 LaserCheck P3:FH traces SF6 gas contained in the fume hood with world-leading ppb sensitivity and data logging according to ASHRAE 110-2016/DIN EN 14175.

Composed of a base unit, comprising the measuring cell, laser, vacuum pump, and a controller. A WIN PC (Win 7.8.20) running a customer control software serves as the man-machine interface. The software controls the measuring process, visualizes its results, and processes user inputs such as parameter settings while storing resulting data for evaluation.

The product contains one SF6 LaserCheck P3:FH system with operating and evaluation software, one internal vacuum pump, and one control computer.

Delivery time may take 3 to 4 weeks once ordered. The warranty for this system expires after 12 months from purchase.



ANSI/ASHRAE Standard 110-2016

The ANSI/ASHRAE Standard 110-2016 specifies a quantitative and qualitative test method for evaluating fume containment of laboratory fume hoods. Applying to conventional, bypass, auxiliary air, and variable-air-volume fume hoods, it is primarily intended for laboratory and factory testing by may be used as an aid in evaluating installed performance as well. For more information about this standard, download below.

Download Now

Technical Specification

Specification
Value
Detection Cell Photoacoustic
Temperature Range

Operating: 15 °C to 35 °C

Storage: 0 °C to 45 °C
Measuring Speed 7 seconds
Measuring Range 6 ppb or 30 ppm SF6
Resolution 1.5 ppb
Compressed Air Supply 5 to 8 bar
Dry
Clean
Free of Oil
Self Diagnostics Continuous
Laser Class 1; no protective measures required
Dimensions 19″ x 6 HE x 520 mm

Downloads

For further supporting documentation for SF6 LaserCheck P3:FH, please see below.

Download Brochure

SF6 LaserCheck P3:FH – Accessories and Replacement Parts

There are a number of accessories and replacement parts available for the SF6 gas containment testing system, which can be found below. Please contact us if you would like more information or to place an order.
