Libreria video
ION Science ha creato una serie di brevi video per informazioni sull’industria e sulle applicazioni, informazioni sulle apparecchiature di rilevamento dei gas e supporto sui prodotti.
Casa » Rilevatori di gas e di fughe » Centro risorse » Video
ION Science ha creato una serie di brevi video per informazioni sull’industria e sulle applicazioni, informazioni sulle apparecchiature di rilevamento dei gas e supporto sui prodotti.
The Tiger handheld VOC gas detector is a revolutionary portable PID instrument for rapid, accurate detection of volatile organic compounds (VOCs).
The Tiger Select is a portable benzene gas detector with two operation modes for rapid detection of benzene and Total Aromatic Compounds (TACs) providing accurate, reliable data.
The Cub personal gas detector is worn within the breathing zone to detect volatile organic compounds, keeping you safe within your working environment.
The instrument’s dual-beam UV absorption technology means that the mercury vapour detector does not saturate or need regenerating between readings – like traditional gold film detection methods – eliminating instrument downtime.
Titan samples gas from the environment once per minute and within just 60 seconds an accurate benzene measurement is displayed!
This robust fixed Continuous VOC Gas Detector has a selectable detection range of 0 – 10 ppm, 0 – 100 ppm or 0 – 1000 ppm and is ideal for use in manufacturing and process industries where VOCs are typically present.
The Falco & Falco TAC is a fixed VOC detector that eliminates false readings found with other competing technology and continuously detection Volatile Organic Compounds (VOCs) in hazardous areas.
GasClam 2 Continuous Ground Gas Detector collects unmanned continuous ground gas concentration data as well as parameters that are known to control it.
Tiger LT is an entry-level handheld VOC gas detector that provides you with fast, accurate, reliable results, however challenging your environment.
With work exposure limits so low it has never been more important to have equipment that can detect benzene down to ppb levels.
See the contents in the box and what you receive when you order an ARA gas detector for worker safety
The term Part Per Million is fairly self-explanatory, it’s simply the dilution of one matter into another but what does it actually look like?
Find out more about the ARA gas detector, its functionality and models for H2S, CO, SO2 and O2 gas detection.
This video will demonstrate on how to use the Panther gas leak detector
© 2024 Ion Science Italy. Ion Science è un marchio registrato su Ion Science Ltd
Diffusion Fixed Gas Detection Device
A diffusion gas detection device works, as the name suggests, on the diffusion principle. The sensor is exposed to the ambient air and will measure the gas by means of the diffusion principle. Diffusion means proportional spread of molecules over the available space (from high concentration to low concentration). This also means that a diffusion gas detection device is only able to measure the concentration of gases at the location where the device is located. Since there is no forced flow of the gas to be measured, this device is not suitable for taking measurements remotely, but they do accurately identify what’s present in a given location.
Pumped Fixed Gas Detection Device
Pumped instruments are equipped with a built-in sampling pump. This means that the device is constantly drawing in gases. A sampling hose may be connected to extend the reach. This means that you can take a measurement from a safe distance so you have an idea of which gases will be present in which concentration before you are exposed to this environment. This allows you to make an appropriate risk analysis and make the right strategy and PPE choices based on the measurement results. By positioning the measuring hose correctly, you can also make a correct measurement at different heights to chart all risks.
Request a quote — HubSpot form
Register your instrument placeholder for Hub Spot Form
Scorri per confrontare più sensori OEM
Scorri per confrontare tutti i sensori di gas OEM, seleziona per nascondere i sensori per confrontare le varianti più adatte.
Nascondere | ||||||||
---|---|---|---|---|---|---|---|---|
Specifiche Comparative | ||||||||
Variante del sensore | MiniPID 2 PPM WR | MiniPID 2 PPM | MiniPID 2 PPB WR | MiniPID 2 PPB | MiniPID 2 HS | MiniPID 2 10.0 eV | MiniPID 2 11.7 eV | MiniPID 2 PPB XF |
Colore pila elettrodi | Blu | Blue | Bianca | Bianca | Rosso | Spot bianco + oro | Bianca | Bianco + Filtro |
Limite di rilevamento minimo | 500 ppb | 100 ppb | 20 ppb | 1 ppb | 0.5 ppb | 5 ppb | 100 ppb | 1 ppb |
Gamma | 0 to >10,000 ppm | 0 to 4000 ppm | 0 to >200 ppm | 0 to >40 ppm | 0 to >3 ppm | 0 to >100 ppm | 0 to >100 ppm | >40 ppm |
Tempo di risposta T90 (s) | <3 | <3 | <8 | <8 | <12 | <8 | <8 | <12s |
Sensibilita | >0.4 mV/ppm @ 100 ppm | >0.65 mV/ppm @ 100 ppm | >5 mV/ppm | >30 mV/ppm | >600 mV/ppm | >15 mV/ppm | >1 mV/ppm | >30 mV/ppm |
Energia della lampada | 10.6 eV | 10.6 eV | 10.6 eV | 10.6 eV | 10.6 eV | 10.0 eV | 11.7 eV | 10.6eV |
Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto | Dettagli del prodotto |
