Sulfur Hexafluoridedetecting-sulfur-hexafluoride

Formula: SF6 | CAS: 2551-62-4

Detecting sulfur hexafluoride: SF6 the most powerful greenhouse gas emissions known to humanity which have alarmingly risen rapidly in recent years!

A Health and Environmental Risk, Using SF6 On A Day to Day Basics

Cheap and non-flammable, SF6 is a colorless, odorless, synthetic gas. It makes a hugely effective insulating material for medium and high-voltage electrical installations.

It is widely used across the electrical industries, from large power stations to wind turbines to electrical sub-stations in towns and cities. It prevents electrical accidents and fires.

“SF6 world production was at 7,000 tons in 1993 and was expected to reach 10,000 metric tons per year by 2010. The electrical industries use approximately 80% of that amount. In 2002, SF6 emissions from the US electric power industry totalled nearly 600 metric tons, that equates to 14.1-million tons of CO2, or 5% of total greenhouse gas emissions from US industrial processes”.
– Grand View Research

Monitoring of SF6, How Damaging to The Climate is SF6?

SF6 in its pure state is inert, colorless, tasteless, non-flammable, and nontoxic. It is heavier than air and can accumulate in cable trenches, pits, and tunnels. A volume greater than 19% in the air may cause asphyxiation. An appropriate risk assessment should be undertaken in order to determine if cable trenches/tunnels are classified as confined spaces, in which case appropriate control measures for access must be implemented.

Identifying SF6 Exposure and The Important’s of Why Detecting Sulfur Hexafluoride Early is Critical

Under normal circumstances, it might be considered rare to be exposed to SF6 without enough oxygen dilution; but for utility employees, this type of exposure is well within the normal course of duties when working on SF6 filled switchgear in enclosed spaces. Indeed, if a substantial quantity of SF6 gas leaks in an enclosed area, it can pose a real danger of asphyxiation to personnel

Select another gas

Gas Fact Sheet

Everything You Need to Know about Detecting Sulfur Hexafluoride

Our Gas Fact Sheets which is available to download below provides you with key information on the exposure limits and the locations where potentially harmful gases can occur. We also share information on gas detection monitoring techniques and equipment that can help you manage gas detection in the workplace, for worker and site safety.

detecting-sulfur-hexafluoride instrument-gas-factsheet

Download Gas Factsheet

Detecting Sulfur Hexafluoride

Formula: SF6 | CAS: 2551-62-4

Synonyms: sulfur hexafluoride, sulfur fluoride

Specification Value/Information
Formula SF6
CAS no. 2551-62-4
Gas Response Factor, 11.7 eV NA
Gas Response Factor, 10.6 eV ZR
Gas Response Factor, 10.0 eV ZR
ppm per mg/m⁻³, (20 °C, 1 bar) 0.165
Molecular Weight, g/mole 146.1
Melting point, °C '-50
Boiling point, °C '-64
Flash point, °C '-
Lower Explosive Limit, % '-
Specification Value/Information
Density, g.cm⁻³ 6.409
Ionisation Energy, eV 19.3
EH40 TWA, ppm 1000
EH40 TWA, mg.m⁻³ 6070
EH40 STEL, ppm 1250
EH40 STEL, mg.m⁻³ 7590
NIOSH TWA REL, ppm 1000
NIOSH TWA REL, mg.m⁻³ 6000
OSHA TWA PEL, ppm 1000
OSHA TWA PEL, mg.m⁻³ 6000
