Portable SF6 Leak Monitor

SF6 Leakmate

Portable SF6 Leak Detector

The SF6 Leakmate, portable SF6 leak detector is a great device for mobile SF6 leak detection. In practical use, it has a SF6 detection threshold of 1 x 10E-6 mbar l/s, which makes it perfectly suitable for simple SF6 leak detection applications on SF6 switchgear. The easy to use, processor controlled portable SF6 leak detector, features both an audible alarm and an LED bar graph display, allowing estimation if a small, medium or big SF6 leak is being detected.

Inquire NowDownload Brochure

Features

The portable SF6 leak detector automatically compensates all ambient influences like temperature changes or movement of air in the room. Intelligent control sets up the instrument appropriately for the ambient situation.

It then uses the present gas concentration as its zero line and begins to look for even higher gas concentrations, which by all means occur when a SF6 leak is detected. This will again be indicated audibly and visually.

Ultimate Performance

  • Threshold of 1 x 10E-6 mbar l/s
  • Simple leak detection applications on SF6 switchgear

Ultimate Safety

  • Battery test display
  • Automatic zero
  • Audible alarm
  • LED bar graph display

Ultimate Flexibility

  • Selectable sensitivity

Technical Specification

Specification
Value
Detector High Voltage Ionisation
Sensitivity 1 x 10E-6 mbar 1,s for SF6
Response Time Approx 1s
Audio Sound pitch proportionally follows leak rate
Sniffing Probe 355 mm flexible pipe
Operating Temperature Range – 20 to 50 °C
EMC Rating CE declaration of conformity
Weight and Dimensions 2100 g including accessory
330 x 280 x 125 including transport case

* All specifications quoted are at calibration point and under the same ambient conditions.
Specifications are based on isobutylene calibration at 20 ËšC, 90% RH and 1000 mBar
*Model dependant.

Download Brochure

Downloads

For further supporting documentation for SF6 Leakmate, portable SF6 leak monitor please see below.

Brochures

Company Documents

Manuals

SF6 Leak, portable SF6 leak monitor – Accessories and Replacement Parts

There are a number of accessories and replacement parts available for the portable SF6 leak monitor, which can be found below. Please contact us if you would like more information or to place an order.
