Tiger XTL

Portable VOC gas detector, low on cost and high on performance!

The Tiger XTL portable VOC gas detector is a variant of the hugely popular Tiger, but low on cost and high on performance. The portable VOC gas detector utilizes revolutionary, patented photoionization detection (PID) sensor technology with humidity resistance. The anti-contamination design provides market-leading accuracy and run-time for any gas detection scenario.

etl_certification kgs_certification IECEx certification ATEX certfication

Inquire Now Download Brochure

Back to all Portable Gas Detectors

Features

The Tiger XTL portable VOC gas detector offers simple, one-handed operation even when wearing the thickest of gloves. The Tiger XTL has a thermo plastic elastomer outer moulding, this rubber material is semi-conductive making the Tiger XTL intrinsically safe.

The large, clear backlit display allows for easy viewing in any light condition. An integrated torch is designed for directing the instrument’s probe into dimly lit areas. The illuminated keypad activates when the light is low.

The Tiger XTL has a push to release button for the rechargeable battery allowing for quick, easy and secure battery connection.

Key Features

Improved robust design can withstand harsh environments
IP65 ingress protection against a range of weather conditions
<2 second response time, one of the fastest and most accurate on the market
Instantaneous alarms, RED & AMBER with loud 95 dBA sounder
Humidity resistant and
anti-contamination design ensures optimal performance

Typical Applications

Environmental Monitoring
Soil Contamination Detection
VOCs in Landfill
Confined Space Entry
Emergency Response
Wing Tank Entry
Medical Gases within Hospital
Fugitive Emissions

2 Year Extended Warranty

Step 1) Purchase an ION Science Tiger XTL VOC Gas Detector

Step 2) Register your instrument here within one month of purchase

Step 3) Receive a 2 year extended warranty certificate!

Extend Warranty

Low cost consumables including filters

An integrated torch designed for dimly lit areas

Flashing LEDS (Low & High alarms)

Loud alarms (Sounder 95 dBA at 300mm)

A large, clear backlit display for easy viewing in any light condition

Large clear keypad designed for one handed operation

Vibrations on alarm

Improved robust design

Li-ion battery life up to 24 hours (charge time 8 hours)

Intrinsically safe and meets ATEX, IECEx, North American and Canadian Standards

Minimal Instrument Downtime

The Tiger XTL has been designed with the user in mind for ease of use and servicing. Batteries can be replaced in potentially explosive environments due to the innovative Intrinsically Safe design. Low cost filters and lamps can be easily changed in minutes, minimising instrument downtime.

What’s in the case?

Our standard kits contains the following:-

Tiger XTL Instrument
Tiger XTL Accessory Kit
USB Cable
Mains Adaptor with Multiple Plug Adaptors
Quick Start Guide
Warranty Registration Card
Calibration Certificate
Safety Notice

Inquire Now

Technical Specification

etl_certification kgs_certification IECEx certification ATEX certfication

Specification	Value
Minimum Resolution*	0.1 ppm
Maximum Reading	5,000 ppm
Response Time	T₉₀ < 2 seconds
Accuracy*	± 5% display reading ± 1 digit
Linearity*	5% display reading ± one digit
Intrinsically Safe Approvals	II1GExiaIICT4Ga Tamb = – 15 ^oC ≤Ta ≤+45 ^oC (with Lithium ion Battery Pack) Tamb = – 15 ^oC ≤Ta ≤+40 ^oC (with Alkaline Battery Pack) IECEx ITS 22.0025X ITS-I22ATEX35111X ITS22UKEX0635X 3193491 conforms to UL Std. 913, 61010-1 & Certified to CAN/CSA Std. C22.2 No. 61010-1. Class 1 Division 1. Approval for groups A, B, C & D, T4.
Battery Life	Typical operating time of 24 hours Typical charge time of 8 hours
Lamps	10.6 eV Krypton PID lamp (standard)
Data Logging*	Push-to-log, 128 zones, 80,000 data points
Calibration	Standard calibration 100 ppm isobutylene Custom calibration capability
Alarm	Flashing LED and 95 dBA at 300mm (12”) audible sounder selectable vibrating alarm
Flow Rate	≥ 220 ml/min in ambient conditions (with blocked flow alarm)
Temperature	Operating: -20 to 60 °C, -4 to 140 °F (non Intrinsically Safe) Humidity: 0-99% RH (non condensing)
Protection	Designed to IP65 EMC tested to EN61326-1:2013, EN50270:2015 & CFR 47:2008 Class A
Weight & Dimensions	370 mm (H) x 91 mm (W) x 60 mm (D) 870g

All specifications quoted are at calibration point and under the same ambient conditions.
Specifications are based on isobutylene calibration at 20 ˚C, 90% RH and 1000 mBar
*Model dependant.

Download Brochure

What our customers say

”“We needed a cost effective VOC instrument that was accurate, repeatable and user-friendly as our older one was cumbersome and difficult to use. The ION Science Tiger, purchased from Shawcity, fitted our ergonomic requirement whilst providing an affordable and reliable replacement.”
Philip Milne, Clinical Embryologist, Ninewells Hospital Assisted Conception UnitNinewells Hospital chooses the ION Science Tiger

View Case Study View All Case Studies View All Testimonials

What our customers say

”“We conduct subsoil investigation so it is very important to have in situ information of polluted soils to help us decide the best place to take a sample. Our technical teams work on outdoor sites during all weather conditions so the Tiger’s humidity resistant sensor was the most important feature for our business. Of course, the anti-contamination design was also vital to avoid cross pollution and ensure data integrity.”
Albert Sabanes i Fiter, Director de projectes at GeoambientGeoambient chooses Tiger for humidity resistant sensor

View Case Study View All Case Studies View All Testimonials

Video Library

Downloads

For supporting resources for the Tiger XTL portable VOC gas detector, please see below.

Tiger XTL Portable VOC Gas Detector Accessories and Replacement Parts

There are a number of accessories and replacement parts available for the Tiger XTL Portable VOC gas detector, which can be found below. Please contact us if you would like more information or to place an order.

FAQs

If you have any questions related to the Tiger XTL portable VOC gas detector, please view our frequently asked questions.

Inquire Now

Tiger XTL Portable VOC Gas Detector Enquiry Form

Please complete the form below and a member of our team will contact you shortly.

Global Distributors

All ION Science distributors are trained to the highest standards to provide you with access to our product portfolio locally, along with the best possible service and support. Find your local representative.

Where to buy

Hide
Comparative specifications
Sensor Variant	MiniPID 2 PPM WR VOC Sensor	MiniPID 2 PPM VOC Sensor	MiniPID 2 PPB WR VOC Sensor	MiniPID 2 PPB VOC Sensor	MiniPID 2 HS VOC Sensor	MiniPID 2 10.0 eV VOC Sensor	MiniPID 2 11.7 eV VOC Sensor
Electrode Stack Colour	Blue	Blue	White	White	Red	White + Gold Spot	White
Minimum Detection Limit	500 ppb	100 ppb	20 ppb	1 ppb	0.5 ppb	5 ppb	100 ppb
Range	0 to >10,000 ppm	0 to 4000 ppm	0 to >200 ppm	0 to >40 ppm	0 to >3 ppm	0 to >100 ppm	0 to >100 ppm
Response Time T90 (s)	<3	<3	<8	<8	<12	<8	<8
Sensitivity	>0.4 mV/ppm @ 100ppm	>0.65 mV/ppm @ 100 ppm	>5 mV/ppm	>30 mV/ppm	>600 mV/ppm	>15 mV/ppm	>1 mV/ppm
Lamp Energy	10.6 eV	10.6 eV	10.6 eV	10.6 eV	10.6 eV	10.0 eV	11.7 eV
	Product Details	Product Details	Product Details	Product Details	Product Details	Product Details	Product Details
